產品特點： |
||
| 1、掃描速度極快,測量點分布規則； | |||
| 2、精度高,單次測量范圍大； | |||
| 3、大景深； |
|
參 數 Parameter |
內 容 Content |
描 述 Description |
||
|
微顯示芯片 Micro-display Panel |
0.3" DMD TRP |
Single Panel |
||
|
分辨率 Resolution |
1280 × 720 | 720P HD | ||
|
畫幅比例 Aspect Ratio |
16 : 9 | |||
|
輻射通量 Radiation Flux (mW) |
300 | |||
|
光源 Light Source |
B-LED | |||
|
壽命(小時) Lifetime(hrs) |
10000 | |||
|
投射比 Throw Ratio |
0.93 - 1.13 | |||
|
對比度 Contrast |
300 : 1 | Full on / Full off | ||
|
均勻性 Uniformity(JBMA) |
>90% | JBMA | ||
|
TV 畸變 TV Distortion |
<0.5% | |||
|
調焦方式 Focusing |
Manual | |||
|
偏軸率 Offset |
0% | |||
|
投射尺寸(英寸) Projection Size (inch) |
14.3" ~ 80" | @350 ~ 2000mm | ||
|
尺寸 Dimension(mm) |
80 × 70 × 27.5 | w/o heatsink | ||
| 1.7 | DOF：-108 ~ 133mm | |||
| F / # | 2.0 | DOF：-105 ~ 162mm | ||
| @WD 600mm | 2.4 | DOF：-122 ~ 200mm | ||
| 4.0 | DOF：-179 ~ 443mm | |||
